» Film-Tech Forum ARCHIVE   » Operations   » Film Handlers' Forum   » Simplex SH1000 needs new gasket....tips? (Page 2)

This topic comprises 2 pages: 1  2

Author Topic: Simplex SH1000 needs new gasket....tips? Mark Gulbrandsen Resident Trollmaster Posts: 16657 From: Music City Registered: Jun 99 posted 06-07-2009 06:24 PM                     Yes, I think it is a Lucas lubricant display... what ever the stuff is it sure works good. Mark  |  IP: Logged Monte L Fullmer Film God Posts: 8367 From: Nampa, Idaho, USA Registered: Nov 2004 posted 06-07-2009 10:01 PM                     ...maybe in low rpm status, but not in car motors where the Lucas causes the oil to foam up horribly in the crankcase.. ..don't put Lucas in that H3 of yours..  |  IP: Logged Frank Angel Film God Posts: 5305 From: Brooklyn NY USA Registered: Dec 1999 posted 06-08-2009 05:11 AM                        Will keep all of the advice posted here as future reference, but actually (and I feel really embarrassed about this), but as per Dick's question, quote: Dick Prather Have you just tried tightening all the gearbox screws? all it took was tighening the screws and the oil leak is now history. Sometimes it's the simplest things....!  |  IP: Logged Monte L Fullmer Film God Posts: 8367 From: Nampa, Idaho, USA Registered: Nov 2004 posted 06-08-2009 07:19 PM                     Isn't that of of the fun things about life - using and fixing things with simple methods? ..and look at the money saved in doing so.. -Good luck in your find. - Monte  |  IP: Logged System Notices Forum Watchdog / Soup Nazi Posts: 215 Registered: Apr 2004 posted 06-21-2010 10:48 AM                 It has been 377 days since the last post.  |  IP: Logged Eric Robinson Jedi Master Film Handler Posts: 538 From: Santa Rosa, CA Registered: Jan 2005 posted 06-21-2010 10:48 AM                     quote: Dave Macaulay Change the motor bearings to 2RS while you're at it, removing the grease cups and plugging their holes with 1/8NPT plugs. I am rebuilding an SH1000 and was wondering if changing the motor bearings as stated above is a common practice?  |  IP: Logged Josh Jones Redhat Posts: 1207 From: Plano, TX Registered: Apr 2000 posted 06-29-2010 04:59 PM                        Usually only if the motor needs it. I would disconnect the motor and let it run without load. If it runs smoothly and quietly, then I left well enough alone. Also, unlike the RCA's the Simplex flywheel was press fit or something. I found it really difficult to get the flywheel off. JJ  |  IP: Logged Eric Robinson Jedi Master Film Handler Posts: 538 From: Santa Rosa, CA Registered: Jan 2005 posted 07-07-2010 05:13 PM                     I'm trying to figure out how to take this apart:  |  IP: Logged Robert Throop Master Film Handler Posts: 412 From: Vernon, NY USA Registered: Jun 99 posted 07-07-2010 05:49 PM                     That is a rotary stabilizer flywheel that goes on the sound drum shaft. It's filled with oil. Why do you want to take it apart? Do you suspect the oil's leaked out?  |  IP: Logged Eric Robinson Jedi Master Film Handler Posts: 538 From: Santa Rosa, CA Registered: Jan 2005 posted 07-08-2010 02:48 PM                     This unit has been reported as "bad" by a third party projection tech. I wanted to disassemble it to see if I could rebuild or repair it.  |  IP: Logged Richard Hamilton Phenomenal Film Handler Posts: 1341 From: Evansville, Indiana Registered: Jan 2000 posted 07-08-2010 03:05 PM                     hehe is he union?  |  IP: Logged Tony Bandiera Jr Film God Posts: 3067 From: Moreland Idaho Registered: Apr 2004 posted 07-09-2010 05:30 PM                     Richard: Good one. Eric: Those stabilizers don't go bad..unless the oil has leaked out. And you would know that easily by both lack of weight and the "feel" as you rotate it. They cannot be readily disassembled, unless you feel like drilling out all those rivets around the edge. (And IIRC the metal is rolled over on the edge so you still won't get it apart.) Short answer is it's not worth trying to "fix" it. The only thing I've seen break on them is the machined "clamps" that secure it to the shaft. I'm still trying to figure out a solution for that problem. I may have another one floating around here if you need one.  |  IP: Logged Louis Bornwasser Film God Posts: 4441 From: prospect ky usa Registered: Mar 2005 posted 07-10-2010 09:15 AM                        We have had good luck using the current 5-star flywheel on there, if it is really a problem. I concur. Weigh it and if it is the same as another, leave it alone. The oil can be sluggish when cold so warm booths are desireable. Louis  |  IP: Logged Eric Robinson Jedi Master Film Handler Posts: 538 From: Santa Rosa, CA Registered: Jan 2005 posted 07-13-2010 06:26 PM                     Here are some pics of the gears in the sound head: Looks like I'll need a new set.  |  IP: Logged

All times are Central (GMT -6:00)

This topic comprises 2 pages: 1  2

Printer-friendly view of this topic
