Topic: Sound leaking from behind screen
|
Cameron Glendinning
Jedi Master Film Handler

Posts: 845
From: West Ryde, Sydney, NSW Australia
Registered: Dec 2005
|
posted 02-19-2010 06:25 PM
Ok, The main issue to find out is what is the actual problem. There are a variety of different types of sound leakage and different causes.
Is it shake? Is it audible bass? Is it midrange? Is it full range?
Is the building full concrete construction?
The worst case of sound leakage I ever found was caused by a small DRILLED hole in the backstage wall caused by an intercom installation. It cost $5 to fix with a tube of silicone sealant.
Another common cause is that speaker boxs vibrate, these vibrations are transfered into the walls and then can be reproduced through thin materials, ie air con ducting, plaster walls or windows. Think of two tin cans on a string with the role of the string being played by the wall.
The only perfect solution is to build a free floating room within the room, starting with a floating floor and were no parts of the inside walls or frames touch the outer walls. Think double glassing windows, think expensive.
The main aim is that when the soundwaves are transfered into vibrations when they hit the wall, they then transfere back to sound waves in the air between the walls, they are now so weak they will not make it through the next wall. The air gap is very important.
So when you do go backstage, do the cheap things first, check for cracks and gaps in the backstage walls/ roof and place rubber mats under the speakers and sub woofers and see what happens. Adding fiberglass on the back wall if there isn't any will make your theater sound MUCH better but possably wont effect the leakage.
Anyway has switching off the sub fixed the problem at all?
| IP: Logged
|
|
|
|
|
|
|
|
|
|
Cameron Glendinning
Jedi Master Film Handler

Posts: 845
From: West Ryde, Sydney, NSW Australia
Registered: Dec 2005
|
posted 02-19-2010 09:15 PM
quote: Richard May I think building a wall and ceiling inside the existing one will help a lot. My main concern is what type of insulation to use.
What materials are used in the buildings construction? is iyt a mix of concrete, brick and drywall?
Ok its a full range muffled sound, If there is any treble at all it is a physical hole or crack that the sound will be travelling through.
A muffled full range sound with no treble implies to me that the sound is travelling through vibrations through the walls and being reproduced by materials inside the unit.
Now if you spend lots of money (plus close the screen while they work)on a 3 layered soundproof drywall and ceiling, the best insulation is the air gap, so make sure that the new wall and its supports, does not in anyway touch the old wall and ceiling.
If you build this wall perfectly and the trouble is caused by transfere of vibration of the speakers directly into the floor first then through the walls, there will be absolutely no improvement in leakage problem.
As I said before, start with the cheap options first, look for cracks and make sure you use rubber mats (or even tennis balls somehow?) to isolate the vibrations from the speaker boxes into the floors or screen frame first.
As for insulation (3.5 kilograms per square meter is a good start), place it on the inside the cinema side of the wall so that your audience will get the THX like sounding results. ie fiberglass, multi layer wall, air gap then existing walls.
| IP: Logged
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Julio Roberto
Jedi Master Film Handler
Posts: 938
From: Madrid, Madrid, Spain
Registered: Oct 2008
|
posted 03-05-2010 04:18 PM
Low frequencies are always a bitch to block.
Too bad this stuff is not readily commercially available.
http://link.aip.org/link/?APPLAB/96/041906/1
quote: THE rumbling bass from the party animals next door need no longer keep you awake at night. Cheap and effective soundproofing can be yours in the shape of novel tiles made from latex and a few plastic buttons.
Low-frequency sounds, especially, seem to seep through most domestic walls. That's because of their long wavelength, says Zhiyu Yang at the Hong Kong University of Science and Technology in Kowloon. Bass sounds at 100 hertz have a wavelength of over 3 metres in air, "and several times longer in solids", he says.
To block out all sound, buildings would need walls several metres thick. Now Yang and his team have developed soundproof panels made of latex and plastic buttons, that will do the job.
These noise-cancelling panels consist of a latex rubber membrane stretched over a 3-millimetre-thick rigid plastic grid of 1-centimetre-wide squares. In the middle of each square is a small, weighted, plastic button.
When sound waves hit the panel, the membrane and weighted buttons resonate at difference frequencies. "The inner part of the membrane vibrates in opposite phase to the outer region," says Yang. That means the sound waves cancel each other out and no sound gets through.
Each weighted membrane only cancels out sound waves within a small band of frequencies. But changing the weight of the buttons alters the operational frequency, says Yang. By stacking five membranes together, each tuned to a specific band, you can create a soundproof panel that works in the range from 70 to 550 hertz.
| IP: Logged
|
|
|
|
